SWI 1008UF Series
1008
inch
High Frequency Wirewound Chip Inductors
Halogen
Halogen-free
Pb
Pb-free
Impedance vs Frequency, DC Bias Characteristics (Typical)
Specifications
Part Number
Inductance
(
nH)
Tolerance Test Frequency
(
Hz)
Q @Test F
req. min.
I rms (mA)
max.
DCR (
Ω
)
max. SRF (MHz) min.
SWI1008UF-3R9
□
3900
G, J,K
0.1
V/7.9M
20/25
260
3.6
100
SWI1008UF-4R7J
4700
J
0.1
V/7.9M
18/7.9
200
4
32
SWI1008UF-5R6
□
5600
G, J,K
0.1
V/7.9M
18/7.9
240
4.0
45
SWI1008UF-6R8
□
6800
G, J,K
0.1
V/7.9M
18/7.9
200
4.9
40
SWI1008UF-8R2
□
8200
G, J,K
0.1
V/7.9M
18/7.9
170
6.0
25
SWI1008UF-100
□
10000
G, J,K
0.1
V/2.52M
18/7.9
150
8.0
25
□
:
C=
±
0.2
nH , S=
±
0.3
nH , G=
±
2% ,
J=
±
5% ,
K=
±
10%
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
Impedance vs Frequency, DC Bias Characteristics (Typical)
(1008
inch)
Specifications
Part Number
Inductance
(
nH)
Tolerance
Test
Frequency
(
Hz)
Q
@
Test Freq.
min.
I rms
(
mA) max.
DCR
(
Ω
)
max.
SRF
(
MHz) min.
SWI1008UF-2R7J
2700
J
0.1
V/7.9M 22/25
290
3.20
140
SWI1008UF-3R3
□
3300
G, J,K
0.1
V/7.9M 22/25
290
3.40
110
SWI1008UF-3R9
□
39 0
G, J,K
0.1
V/7.9M
0/25
260
3.6
100
SWI1008UF-4R7J
4700
J
0.1
V/7.9M 18/7.9
200
4
32
SWI1008UF-5R6
□
5600
G, J,K
0.1
V/7.9M 18/7.9
240
4.0
45
SWI1008UF-6R8
□
6800
G, J,K
0.1
V/7.9M 18/7.9
200
4.9
40
SWI1008UF-8R2
□
8200
G, J,K
0.1
V/7.9M 18/7.9
170
6.0
25
SWI1008UF-100
□
10000
G, J,K 0.1V/2.52M 18/7.9
150
8.0
25
□ :
C=±0.2nH , S=±0.3nH , G=±2% , J=±5% , K=±10%
83
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the speci cations without prior noti cation.
For the latest speci cation, please visit our website:
Remark
