SWI 0805UF Series
0805
inch
High Frequency Wirewound Chip Inductors
Halogen
Halogen-free
Pb
Pb-free
Impedance vs Frequency, DC Bias Characteristics (Typical)
Specifications
Part Number
Inductance
(
nH)
Tolerance Test Frequency
(
Hz)
Q @Test
Freq min.
I rms (mA)
max.
DCR (
Ω
)
max. SRF (MHz) min.
SWI0805UF-R39
□
390
G,J
0.1
V/100M
48/250
290
1.50
560
SWI0805UF-R47
□
470
G,J
0.1
V/50M
33/100
250
1.70
375
SWI0805UF-R56
□
560
G,J
0.1
V/25M
23/50
230
1.90
340
SWI0805UF-R62
□
620
G,J
0.1
V/25M
23/50
210
2.20
220
SWI0805UF-R68
□
680
G,J
0.1
V/25M
23/50
190
2.20
188
SWI0805UF-R82
□
820
G,J
0.1
V/25M
23/50
180
2.35
215
SWI0805UF-1R0
□
1000
G,J
0.1
V/25M
20/50
170
2.5
100
SWI0805UF-1R2
□
1200
G,J
0.1
V/7.9M
18/25
170
2.5
100
□
:
C=
±
0.2
nH , S=
±
0.3
nH , G=
±
2% ,
J=
±
5% ,
K=
±
10%
Impedance vs Frequency, DC Bias Characteristics (Typical)
Specifications
Part Number
Inductance
(
nH)
Tolerance
Test
Frequency
(
Hz)
Q
@
Test Freq.
min.
I rms
(
mA) max.
DCR
(
Ω
)
max.
SRF
(
MHz) min.
SWI0805UF-R27
□
270
G,J
0.1
V/100M 48/250
350
1.00
650
SWI0805UF-R33
□
330
G,J
0.1
V/100M 48/250
310
1.40
600
SWI0805UF-R39
□
390
G,J
0.1
V/100M 48/250
290
1.50
560
SWI0805UF-R47
□
470
G,J
0.1
V/50M 33/100
250
1.70
375
SWI0805UF-R56
□
560
G,J
0.1
V/25M 23/50
230
1.90
340
SWI0805UF-R62
□
620
G,J
0.1
V/25M 23/50
210
2.20
220
SWI0805UF-R68
□
680
G,J
0.1
V/25M 23/50
190
2.20
188
SWI0805UF-R82
□
820
G,J
0.1
V/25M 23/50
180
2.35
215
SWI0805UF-1R0
□
1000
G,J
0.1
V/25M 20/50
170
2.5
100
SWI0805UF-1R2
□
1200
G,J
0.1
V/7.9M 18/25
170
2.5
100
□ :
C=±0.2nH , S=±0.3nH , G=±2% , J=±5% , K=±10%
81
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the speci cations without prior noti cation.
For the latest speci cation, please visit our website:
Remark
