DC Dias Characteristics (Typical)
TPRHC1204 Series
5050
inch
Dimensions
Specifications
Chip Size
Units: mm
A
12.80
max..
B
12.80
max..
C
5.00
max..
D
5.00
ref.
E
2.20
ref.
F
7.60
ref.
Part Number
Inductance (uH)
Tolerance (%)
Test Frequency (Hz)
DCR (
Ω
)
max.
I sat (A) max
TPRHC 1204F-3R9Y
3.9
±
30%
1
V/100K
0.015
6.50
TPRHC 1204F-4R7Y
4.7
±
30%
1
V/100K
0.018
5.70
TPRHC 1204F-6R8Y
6.8
±
30%
1
V/100K
0.023
4.90
TPRHC 1204F-8R2Y
8.2
±
30%
1
V/100K
0.026
4.60
TPRHC 1204F-100M
10
±
20%
1
V/100K
0.028
4.50
TPRHC 1204F-220M
22
±
20%
1
V/100K
0.07
2.90
TPRHC 1204F-330M
33
±
20%
1
V/100K
0.097
2.70
TPRHC 1204F-470M
47
±
20%
1
V/100K
0.160
1.90
TPRHC 1204F-560M
56
±
20%
1
V/100K
0.190
1.80
TPRHC 1204F-680M
68
±
20%
1
V/100K
0.220
1.50
TPRHC 1204F-101M
100
±
20%
1
V/100K
0.308
1.20
TPRHC 1204F-221M
220
±
20%
1
V/100K
0.700
0.80
TPRHC 1204F-331M
330
±
20%
1
V/100K
0.990
0.50
Note:
Isat
：
Based on inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△
T
：
40
℃
typ.
）
Assembly Type Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All thedata listed in thiscatalogueare for referenceonly,TAI-TECH reserves the right to alteror revise the specificationswithout prior
notification.
For the latest specification,please visit ourwebsite:www.tai-tech.com.tw
Assembly Type Power Inductors
(5050
inch)
Dimensions
Specifications
Chip Size
A
12.80
max..
B
12.80
max..
C
5.00
max..
D
5.00
ref.
E
2.20
ref.
F
7.60
ref.
Units: mm
Part Number
Inductance
(
uH)
Tolerance
(%)
Test Frequency
(
Hz)
DCR
(
Ω
)
max.
I sat
(
A) max
TPRHC1204F-3R9Y
3.9
± 30%
1
V/100K
0.015
6.50
TPRHC 1204F-4R7Y
4.7
± 30%
1
V/100K
0.018
5.70
TPRHC1204F-6R8Y
6.8
± 30%
1
V/100K
0.023
4.90
TPRHC1204F-8R2Y
8.2
± 30%
1
V/100K
0.026
4.60
TPRHC 1204F-100M
10
± 20%
1
V/100K
0.028
4.50
TPRHC 1204F-220M
22
± 20%
1
V/100K
0.07
2.90
TPRHC 1204F-330M
33
± 20%
1
V/100K
0.097
2.70
TPRHC1204F-470M
47
± 20%
1
V/100K
0.160
1.90
TPRHC1204F-560M
56
± 20%
1
V/100K
0.190
1.80
TPRHC 1204F-680M
68
± 20%
1
V/100K
0.220
1.50
TPRHC 1204F-101M
100
± 20%
1
V/100K
0.308
1.20
TPRHC1204F-221M
220
± 20%
1
V/100K
0.700
0.80
TPRHC1204F-331M
330
± 20%
1
V/100K
0.990
0.50
Note:
Isat
：
Basedon inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Basedon temperature rise
（
△
T
：
40
℃
typ.
）
DC Dias Characteristics (Typical)
0
1.4
2.8
4.2
5.6
7
DCCURRENT(A)
0
8
16
24
32
40
INDUCTANCE (uH)
TPRHC1204F-Series
4
R7
6
R8
120
220
330
0
1.6
3.2
4.8
6.4
8
DCCURRENT(A)
0
6
12
18
24
30
TEMP.RISE(
o
C)
TPRHC1204F-Series
4
R7
6
R8
120
220
330
142
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
For the latest specification, please visit our website:
Dimensions
Specifications
Chip Size
A
12.80
max..
B
12.80
max..
C
5.00
max..
D
5.00
ref.
E
2.20
ref.
F
7.60
ref.
Units: mm
Part Number
Inductance
(
uH)
Tolerance
(%)
Test Frequency
(
Hz)
DCR
(
Ω
)
max.
I sat
(
A) max
TPRHC 1204F-3R9Y
3.9
± 30%
1
V/100K
0.015
6.50
TPRHC 1204F-4R7Y
4.7
± 3 %
1
V/100K
0.018
5.70
TPRHC 1204F-6R8Y
6.8
± 30%
1
V/100K
0.023
4.90
TPRHC 1204F-8R2Y
8.2
± 30%
1
V/100K
0.026
4.60
TPRHC 1204F-100M
10
± 20%
1
V/100K
0.028
4.50
TPRHC 1204F-220M
22
± 20%
1
V/100K
0.07
2.90
TPRHC 1204F-330M
33
± 20%
1
V/100K
0.097
2.70
TPRHC 1204F-470M
47
± 20%
1
V/100K
0.160
1.90
TPRHC 1204F-560M
56
± 20%
1
V/100K
0.190
1.80
TPRHC 1204F-680M
68
± 20%
1
V/100K
0.220
1.50
TPRHC 1204F-101M
100
± 20%
1
V/100K
0.308
1.20
TPRHC 1204F-221M
220
± 20%
1
V/100K
0.700
0.80
TPRHC 1204F-331M
330
± 20%
1
V/100K
0.990
0.50
Note:
Isat
：
Based on inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△
T
：
40
℃
typ.
）
DC Dias Characteristics (Typical)
0
1.4
2.8
4.2
5.6
7
DC CURRENT(A)
0
8
16
24
32
40
INDUCTANCE (uH)
TPRHC1204F-Series
4
R7
6
R8
120
220
330
0
1.6
3.2
4.8
6.4
8
DC CURRENT(A)
0
6
12
18
24
30
TEMP. RISE(
o
C)
TPRHC1204F-Series
4
R7
6
R8
120
220
330
142
All the data listed in this catalogue are for reference only, TAI-TECH reserves the rig
notification.
For the latest specification, please visit our website:
Assembly Type Power Inductors
(5050
inch)
Dimensions
Specifications
A
B
C
D
E
F
Units: mm
Part Number
Inductance
(
uH)
Tolerance
(%)
Test Frequency
(
Hz)
TPRHC 1204F-3R9Y
3.9
± 30%
1
V/100K
TPRHC 1204F-4R7Y
4.7
± 30%
1
V/100K
TPRHC 1204F-6R8Y
6.8
± 30%
1
V/100K
TPRHC 1204F-8R2Y
8.2
± 30%
1
V/100K
TPRHC 1204F-100M
10
± 20%
1
V/100K
TPRHC 1204F-220M
22
± 20%
1
V/100K
TPRHC 1204F-330M
33
± 20%
1
V/100K
TPRHC 1204F-470M
47
± 20%
1
V/100K
TPRHC 1204F-560M
56
± 20%
1
V/100K
TPRHC 1204F-680M
68
± 20%
1
V/100K
TPRHC 1204F-101M
100
± 20%
1
V/100K
TPRHC 1204F-221M
220
± 20%
1
V/100K
TPRHC 1204F-331M
330
± 20%
1
V/100K
Note:
Isat
：
Based on inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△
T
：
40
℃
typ.
）
DC Dias Characteristics (Typical)
0
1.4
2.8
4.2
5.6
7
DC CURRENT(A)
0
8
16
24
32
40
INDUCTANCE (uH)
TPRHC1204F-Series
4
R7
6
R8
120
220
330
0
1.6
3.2
DC CU
0
6
12
18
24
30
TEMP. RISE(
o
C)
TPRHC
220
330
142
142
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the speci cations without prior noti cation.
For the latest speci cation, please visit our website:
Remark
