DC Bias Characteristics (Typical)
FWP 565048N Series
2220
inch
Dimensions
Specifications
Chip Size
Units: mm
A
5.60
±0.30
B
5.00
±0.30
C
4.50
±0.30
D
2.00
±0.30
E
3.80
±0.30
F
3.10
±0.30
Part Number
Inductance L0
(
uH)
±
20%@
0
A
Tolerance Test Frequency
(
Hz)
Rated Current
DCR (m
Ω
)
±
20%.
@25
℃
.
Temperature
current I rms (A)
Saturation current
I sat (A)
FWP565048N-1R0M
1.00
±
20%
7.96
M
7.00
6.00
10.0
FWP565048N-2R2M
2.20
±
20%
7.96
M
4.50
4.30
16.0
FWP565048N-3R3M
3.30
±
20%
7.96
M
4.20
3.60
21.0
FWP565048N-4R7M
4.70
±
20%
7.96
M
3.80
3.20
26.0
FWP565048N-6R8M
6.80
±
20%
7.96
M
3.00
2.60
39.0
FWP565048N-100K
10.0
±
10%
2.52
M
2.20
2.00
60.5
FWP565048N-220K
22.0
±
10%
2.52
M
1.50
1.35
143
FWP565048N-330K
33.0
±
10%
2.52
M
1.30
1.10
198
FWP565048N-470K
47.0
±
10%
2.52
M
1.10
0.90
252
FWP565048N-680K
68.0
±
10%
2.52
M
1.00
0.80
360
FWP565048N-101K
100
±
10%
1
K
0.80
0.70
505
FWP565048N-151K
150
±
10%
1
K
0.60
0.55
750
FWP565048N-221K
220
±
10%
1
K
0.55
0.43
1000
Note:
1.
All test data referenced to 25
℃
ambient.
2.
Heat Rated Current (Irms) will cause the coil temperature rise approximately
Δ
t of 40
℃
(
keep 1min.).
3.
Saturation Current (Isat) will cause L0 to drop 30% typical. (keep quickly).
4.
Special inquiries besides the above common used types can be met on your requirement.
Assembly Type Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogueare for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit ourwebsite:www.tai-tech.com.tw
Assembly Type Power Inductors
(1816
inch)
Dimensions
Specifications
PartNumber
InductanceL0
(
uH)±20%
@ 0
A
TestFrequency
(
Hz)
IDC(A)
max.
DCR (mΩ)max.
@25
℃
.
FWP454033N-1R0M
1.00
0.1
V/1M
2.70
48.7
FWP454033N-1R4M
1.40
0.1
V/1M
2.50
56.2
FWP454033N-2R2M
2.20
0.1
V/1M
2.25
71.2
FWP454033N-3R3M
3.30
0.1
V/1M
2.00
86.2
FWP454033N-4R7M
4.70
0.1
V/1M
1.62
108.7
FWP454033N-5R6M
5.60
0.1
V/1M
1.48
125.7
FWP454033N-6R8M
6.80
0.1
V/1M
1.43
131.2
FWP454033N-100M
10.0
0.1
V/1M
1.04
182
FWP454033N-120M
12.0
0.1
V/1M
0.97
210
FWP454033N-150M
15.0
0.1
V/1M
0.85
235
FWP454033N-180M
18.0
0.1
V/1M
0.74
338
FWP454033N-220M
22.0
0.1
V/1M
0.68
378
Note:
1.
All test data referenced to 25
℃
ambient.
2.
HeatRatedCurrent (IDC)will cause the coil temperature rise approximatelyΔtof 40
℃
(
keep1min.).
3.
Special inquiries besides theabove commonused types can bemeton your requirement.
DC Bias Characteristics (Typical)
ChipSize
A
4.50
±
0.30
B
4.00
±
0.30
C
3.00
±
0.30
D
1.30
ref,
Units:mm
FWP454033N-Series
FWP454033N-Series
135
INDUCTANCE(uH)
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
For the latest specification, please visit our website:
Dimensions
Specifications
Chip Size
A
5.60
±
0.30
B
5.00
±
0.30
C
4.50
±
0.30
D
2.00
±
0.30
E
3.80
±
0.30
F
3.10
±
0.30
Units: mm
Part Number
Inductance
L0
(
uH)±20%
@ 0
A
Tolerance Test Frequency
(
Hz)
Rated Current
DCR (mΩ)
±
20%.
@25
℃
.
Tempetature current
I rms (A)
Saturation current
I sat (A)
FWP565048N-1R0M
1.00
± 20%
7.96
M
7.00
6.00
10.0
FWP565048N-2R2M
2.20
± 20%
7.96
M
4.50
4.30
16.0
FWP565048N-3R3M
3.30
± 20%
7.96
M
4.20
3.60
21.0
FWP565048N-4R7M
4.70
±20%
7.96
M
3.80
3.20
26.0
FWP565048N-6R8M
6.80
±20%
7.96
M
3.00
2.60
39.0
FWP565048N-100K
10.0
±10%
2.52
2.20
2.00
60.5
FWP565048N-220K
22.0
±10%
2.52
M
1.50
1.35
143
FWP565048N-330K
33.0
±10%
2.52
M
1.30
1.10
198
FWP565048N-470K
47.0
±10%
2.52
1.10
0.90
252
FWP565048N-680K
68.0
±10%
2.52
1.00
0.80
360
FWP565048N-101K
100
±10%
1
K
0.80
0.70
505
FWP565048N-151K
150
±10%
1
K
0.60
0.55
750
FWP565048N-221K
220
±10%
1
K
0.55
0.43
1000
Note:
1.
All test data ref renced to 25
℃
ambient.
2.
Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40
℃
(
keep 1min.).
3.
Saturation Current (Isat) will cause L0 to drop
30
%
typical.
(
keep quickly).
4.
Special inquiries besides the above common used types can be met on your requirement.
DC Bias Characteristics (Typical)
0
1.5
3
4.5
6
7.5
DC CURRENT(A)
0
8
16
24
32
40
TEMP. RISE(
o
C)
FWP565048N-Series
1
R0
3
R3
150
181
680
0
1.5
3
4.5
6
7.5
DC CURRENT(A)
0
46
92
138
184
230
INDUCTANCE(uH)
FWP565048N-Series
1
R0
3
R3
150
680
181
All the data listed in this catalogue are for reference only, TAI-TECH reserves the righ
notification.
For the latest specification, please visit our website:
Assembly Type Power Inductors
(2220
inch)
Dimensions
Sp ifications
A
B
C
D
E
F
Units: mm
Part Number
Inductance
L0
(
uH)±20%
@ 0
A
Tolerance
Test
Frequency
(
Hz)
Rated Cur
Tempetature current
I rms (A)
S
FWP565033N-1R0M 1.00
± 20% 7.96M
5.00
FWP565033N-2R2M 2.20
± 20% 7.96M
4.00
FWP565033N-3R3M 3.3
± 20% 7.96M
3.60
FWP565033N-4R7M 4.7
±20% 7.96M
3.20
FWP565033N-6R8M 6.80
±20% 7.96M
2.60
FWP565033N-100K 10.0
±10% 2.52M
2.00
FWP565033N-220K 22.0
±10% 2.52M
1.50
FWP565033N-330K 33.0
±10% 2.52M
1.30
FWP565033N-470K 47.
±10% 2.52M
1.02
FWP565033N-680K 68.0
±10% 2.52M
0.85
FWP565033N-101K 100
±10%
1
K
0.75
FWP565033N-151K 150
±10%
1
K
0.50
FWP565033N-221K 220
±10%
1
K
0.41
Note:
1.
All test data referenced to 25
℃
ambient.
2.
Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40
℃
(
keep 1min.).
3.
Saturation Current (Isat) will cause L0 to drop
30
%
typical.
(
keep quickly).
4.
Special inquiries besides the above common used types can be met on your requirement.
DC Bias Characteristics (Typical)
0
1.1
2.2
3.3
4.4
5.5
DC CURRENT(A)
0
8
16
24
32
40
TEMP. RISE(
o
C)
FWP565033N-Series
1
R0
3
R3
150
181
680
0
1.1
2.2
DC CURRE
0
46
92
138
184
230
INDUCTANCE(uH)
FWP565033
150
680
181
136
137
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the speci cations without prior noti cation.
For the latest speci cation, please visit ur website:
Remark
