DC Bias Characteristics (Typical)
SDSL 10D50F Series
4040
inch
Dimensions
Specifications
Chip Size
Units: mm
A
10.20
±0.30
B
10.00
±0.30
C
5.00
max
D
3.00
±0.10
E
1.20
±0.15
F
7.70
±0.30
Part Number
Inductance (uH)
Test Frequency (Hz)
DCR (m
Ω
)
max
I sat (A) max
I rms (A) typ
SDSL10D50F-R80Y
0.8
±
30%
0.1
V/100K
4.30
9.50
13.50
SDSL10D50F-1R5Y
1.5
±
30%
0.1
V/100K
5.80
8.30
10.50
SDSL10D50F-2R2Y
2.2
±
30%
0.1
V/100K
7.20
7.50
9.25
SDSL10D50F-3R3Y
3.3
±
30%
0.1
V/100K
10.40
6.50
7.80
SDSL10D50F-4R7Y
4.7
±
30%
0.1
V/100K
12.30
6.10
6.40
SDSL10D50F-6R8Y
6.8
±
30%
0.1
V/100K
18.00
5.40
5.40
SDSL10D50F-100M
10
±
20%
0.1
V/100K
26.00
4.50
4.45
SDSL10D50F-220M
22
±
20%
0.1
V/100K
61.00
2.90
2.95
SDSL10D50F-470M
47
±
20%
0.1
V/100K
130.0
2.00
2.00
SDSL10D50F-680M
68
±
20%
0.1
V/100K
201.0
1.60
1.65
SDSL10D50F-101M
100
±
20%
0.1
V/100K
253.0
1.35
1.35
SDSL10D50F-121M
120
±
20%
0.1
V/100K
303.0
1.18
1.28
Note:
1.
All test data referenced to 25
℃
ambient.
2.
Heat Rated Current (Irms) will cause the coil temperature rise approximately
Δ
t of 40
℃
(
keep 1min.).
3.
Saturation Current (Isat) will cause L0 to drop 30% typical. (keep quickly).
Assembly Type Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All thedata listed in this catalogueare for referenceonly,TAI-TECH reserves the right to alteror revise the specificationswithout prior
notification.
For the latest specification,please visit ourwebsite:www.tai-tech.com.tw
Assembly Type Power Inductors
(4040
inch)
Dimensions
Specifications
Part Number
Inductance (uH)
Test
Frequency
(
Hz)
DCR (mΩ) max I sat (A )max I rms (A) typ
SDSL10D30F-R80Y
0.80
±30%
0.1
V/100K
0.0057
11.20
8.30
SDSL10D30F-1R5Y
1.5
±30%
0.1
V/100K
0.0110
8.00
5.80
SDSL10D30F-2R2Y
2.2
±30%
0.1
V/100K
0.0169
6.70
5.10
SDSL10D30F-3R3Y
3.3
±30%
0.1
V/100K
0.0210
5.56
4.70
SDSL10D30F-4R7Y
4.7
±30%
0.1
V/100K
0.0300
4.65
4.00
SDSL10D30F-6R8Y
6.8
±30%
0.1
V/100K
0.0350
3.84
3.60
SDSL10D30F-100M
10
±20%
0.1
V/100K
0.0590
3.18
2.80
SDSL10D30F-150M
15
±20%
0.1
V/100K
0.0910
2.60
2.05
SDSL10D30F-220M
22
±20%
0.1
V/100K
0.1430
2.16
1.60
SDSL10D30F-330M
33
±20%
0.1
V/100K
0.2020
1.74
1.35
SDSL10D30F-470M
47
±20%
0.1
V/100K
0.2990
1.43
1.20
SDSL10D30F-680M
68
±20%
0.1
V/100K
0.4290
1.22
0.95
SDSL10D30F-101M
100
±20%
0.1
V/100K
0.6830
1.02
0.70
SDSL10D30F-151M
150
±20%
0.1
V/100K
0.8710
0.84
0.51
Note:
1.
All test data referenced to 25
℃
ambient.
2.
Heat Rated Current (Irms) will cause the coil temperature rise approximatelyΔt of 40
℃
(
keep 1min.).
3.
Saturation Current (Isat) will cause L0 to drop 30% typical.
(
keep quickly).
Chip Size
A
10.20
±
0.30
B
10.00
±
0.30
C
3.00
max
D
3.00
±
0.10
E
1.20
±
0.15
F
7.70
±
0.30
Units: mm
DC Bias Characteristics (Typical)
139
0
2
4
6
8
10
DCCURRENT(A)
0
12
24
36
48
60
INDUCTANCE (uH)
SDSL10D30F-Series
1
R5
6
R8
100
150
330
560
0
1.2
2.4
3.6
4.8
6
DCCURRENT(A)
0
6
12
18
24
30
TEMP.RISE(
o
C)
SDSL10D3 F-Series
1
R5
6
R8
00
150
330
560
