WCM 2012 Series
0805
inch
Dimensions
Specifications
Chip Size
Units: mm
Series A(mm) B(mm) C(mm) C
’
(
mm) D1(mm) D2(mm) E(mm)
F2S
2.0
±0.2 1.2±0.2 1.2±0.2
-
0.55
±0.1 0.46±0.1 0.15±0.1
L2N 2.4 max.
1.6
max.
0.9
±0.1 1.0±0.2 0.55±0.1
-
0.46
±0.1
Part Number
Common mode
Impedance (
Ω
)
Test Frequency
(
MHz)
DC Resistance
(
Ω
)
max.
Rated Current
(
mA)max.
Rated Volt
(
Vdc)max.
Withstand Volt.
(
Vdc) max.
IR (
Ω
)
min.
WCM2012L2NF-900T04
90
±
25%
100
0.35
400
50
125
10
M
WCM2012L2NF-181T03
180
±
25%
100
0.50
300
50
125
10
M
WCM2012F2SF-670T04
67
±
25%
100
0.25
400
50
125
10
M
WCM2012F2SF-900T04
90
±
25%
100
0.30
400
50
125
10
M
WCM2012F2SF-121T04
120
±
25%
100
0.30
400
50
125
10
M
WCM2012F2SF-161T03
160
±
25%
100
0.35
350
50
125
10
M
WCM2012F2SF-181T03
180
±
25%
100
0.35
350
50
125
10
M
WCM2012F2SF-201T03
200
±
25%
100
0.40
300
50
125
10
M
WCM2012F2SF-221T03
220
±
25%
100
0.40
300
50
125
10
M
WCM2012F2SF-261T03
260
±
25%
100
0.40
300
50
125
10
M
WCM2012F2SF-361T03
360
±
25%
100
0.50
300
50
125
10
M
WCM2012F2SF-601T03
600
±
25%
100
0.88
300
50
125
10
M
WCM2012F2SF-102T01
1000
±
25%
100
1.30
100
50
125
10
M
Wirewound Common Mode Chokes
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogue are for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit our website:www.tai-tech.com.tw
D
A
E
C
D
B
Wirewound Common Mode Chokes
(0805
inch)
Dimensions
Specifications
F2S
L2N
Chip Size
Series
A(mm)
B(mm)
C(mm)
C’(mm)
D1(mm)
D2(mm)
E(mm)
F2S
2.0
±0.2
1.2
±0.2
1.2
±0.2
-
0.55
±0.1
0.46
±0.1
0.15
±0.1
L2N 2.4 max.
1.6
max.
0.9
±0.1
1.0
±0.2
0.55
±0.1
-
0.46
±0.1
Unit: mm
Part Number
Common mode
Impedance
(
Ω
)
Test Frequency
(
MHz)
DC
Resistance
(
Ω
)
max.
Rated Current
(
mA)max.
Rated Volt.
(
Vdc)max.
Withstand
Volt. (Vdc)
max.
IR
(
Ω
)
min.
WCM2012L2NF-900T04
90
±2
100
0.35
400
50
125
10
M
WCM2012L2NF-181T03 180±25%
100
0.50
300
50
125
10
M
WCM2012F2SF-670T04
67
±25%
100
0.25
400
50
125
10
M
WCM2012F2SF-900T04
90
±25%
100
0.30
400
50
125
10
M
WCM2012F2SF-121T04 120±25
100
0.30
40
50
125
10
M
WCM2012F2SF-161T03 160±25%
100
0.35
350
50
125
10
M
WCM2012F2SF-181T03 180±25%
100
0.35
350
50
125
10
M
WCM2012F2SF-201T03 200±25%
100
0.40
300
50
125
10
M
WCM2012F2SF-221T03 220±25
100
0.40
30
50
125
10
M
WCM2012F2SF-261T03 260±25%
100
0.40
300
50
125
10
M
WCM2012F2SF-361T03 360±25%
100
0.50
300
50
125
10
M
WCM2012F2SF-601T03
600
±25%
100
0.88
300
50
125
10
M
WCM2012F2SF-102T01 1000±25%
100
1.30
100
50
125
10
M
47
