CTX 5050 Series
Dimensions
Specifications
Series
A(mm)
B(mm)
C(mm)
D(mm)
E(mm)
F(mm)
CTX505028-SN
50
±
0.5
50
±
0.5
2.8
typ.
30
typ.
5.0
typ.
1.2
typ.
CTX505040-SN
50
±
0.5
50
±
0.5
4.0
typ.
30
typ.
5.0
typ.
2.4
typ.
Units: mm
Part Number
Inductance (uH)
Tolerance (%)
Test Frequency (Hz)
DCR(
Ω
)
typ.
Q typ.
Turns
CTX505028-10W5MSN-30-T0
6.3
±
10%
100
K/1V
0.037
90
10
CTX505040-10W5MSN-30-T0
6.0
±
10%
100
K/1V
0.018
80
10
Note:
Efficiency was tested by T.I. Chip set.
Wireless Power Charging-Tx
Halogen
Halogen-free
Pb
Pb-free
P1
Wireless Power Charging-Tx
Dimensions
Specifications
Series
A(mm)
B(mm)
C(mm)
D(mm)
E(mm)
F(mm)
CTX505028-SN 50
±
0.5
50
±
0.5
2.8
typ.
30
typ.
5.0
typ.
1.2
typ.
CTX505040-SN 50
±
0.5
50
±
0.5
4.0
typ.
30
typ.
5.0
typ.
2.4
typ.
Units: mm
Part Number
Inductance
(
uH)
Tolerance
(%)
Test
Frequency
(
Hz)
DCR(
Ω
)
typ.
Q
typ.
Turns
CTX505028-10W5MSN-30-T0
6.3
±
10%
100
K/1V
0.037
90
10
CTX505040-10W5MSN-30-T0
6.0
±
10%
100
K/1V
0.018
80
10
NOTE: Efficiency was tested by T.I. Chip set.
P1
Wireless Power Charging-Tx
Dimensions
Specifications
Series
A(mm)
B(mm)
C(mm)
D(mm)
E(mm)
F(mm)
CTX505028-SN 50
±
0.5
50
±
.5
2.8
ty .
3 .
5.0
typ.
1.2
typ.
CTX505040-SN 50
±
0.5
50
±
0.5
4.0
typ.
30
typ.
5.0
typ.
2.4
typ.
Units: mm
Part Number
Inductance
(
uH)
Tolerance
(%)
Test
Frequency
(
Hz)
DCR(
Ω
)
typ.
Q
typ.
Turns
CTX505028-10W5MSN-30-T0
6.3
±
10%
100
K/1V
0.037
90
10
CTX505040-10W5MSN-30-T0
6.0
±
10%
100
K/1V
0.018
80
10
NOTE: Efficiency was tested by T.I. Chip set.
