DC Bias Characteristics (Typical)
TMPC 0624H Series
2525
inch
Dimensions
Specifications
Chip Size
Units: mm
A
7.00
±0.30
B
6.60
±0.30
C
2.20
±0.20
D
1.80
±0.30
E
3.00
±0.30
Part Number
Inductance L0 (uH)
@ 0
A
I rms (A)
typ
I sat (A)
typ
DCR (m
Ω
)
typ. @25
℃
.
DCR (m
Ω
)
max. @25
℃
.
TMPC0624H-R22MG-D
0.22
±
20%
21.0
34.0
2.0
3.2
TMPC0624H-R47MG-D
0.47
±
20%
15.0
26.0
4.8
5.1
TMPC0624H-R68MG-D
0.68
±
20%
13.0
21.0
6.4
7.2
TMPC0624H-1R0MG-D
1.00
±
20%
11.0
16.0
10.5
13.5
TMPC0624H-2R2MG-D
2.20
±
20%
7.0
14.0
23.0
28.0
TMPC0624H-3R3MG-D
3.30
±
20%
6.0
10.0
34.0
39.0
TMPC0624H-4R7MG-D
4.70
±
20%
5.5
9.0
41.0
50.0
TMPC0624H-5R6MG-D
5.60
±
20%
5.0
8.0
56.0
62.0
TMPC0624H-6R8MG-D
6.80
±
20%
4.0
7.0
65.0
72.0
TMPC0624H-100MG-D
10.0
±
20%
3.2
5.0
92.0
101
Note:
1.
Test frequency : L : 100KHz /1.0V.
2.
All test data referenced to 25
℃
ambient.
3.
Heat Rated Current (Irms) will cause the coil temperature rise approximately
Δ
t of 40
℃
(
keep 1min.).
4.
Saturation Current (Isat) will cause L0 to drop 30% typical. (keep quickly).
5.
Special inquiries besides the above common used types can be met on your requirement.
Molding Type High Current Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogueare for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit our website:www.tai-tech.com.tw
Molding Type High Current Power Inductors
(2525
inch)
Dimensions
Specifications
Chip Size
A
7.00
±
0.30
B
6.60
±
0.30
C
2.20
±
0.20
D
1.80
±
0.30
E
3.00
±
0.30
Units: mm
Part Number
Inductance L0
(
uH) @ 0 A
I rms
(
A)typ
I sat
(
A)typ
DCR (mΩ)
typ. @25
℃
.
DCR (mΩ)
max. @25
℃
.
TMPC0624H-R22MG-D
0.22
±20%
21.0
34.0
2.0
3.2
TMPC0624H-R47MG-D
0.47
±20%
15.0
26.0
4.8
5.1
TMPC0624H-R68MG-D
0.68
±20%
13.0
21.0
6.4
7.2
TMPC0624H-1R0MG-D
1.00
±20%
11.0
16.0
10.5
13.5
TMPC0624H-2R2MG-D
2.20
±20%
7.0
14.0
23.0
28.0
TMPC0624H-3R3MG-D
3.30
±20%
6.0
10.0
34.0
39.0
TMPC0624H-4R7MG-D
4.70
±20%
5.5
9.0
41.0
50.0
TMPC0624H-5R6MG-D
5.60
±20%
5.0
8.0
56.0
62.0
TMPC0624H-6R8MG-D
6.80
±20%
4.0
7.0
65.0
72.0
TMPC0624H-100MG-D
10.0
±20%
3.2
5.0
92.0
101
Note:
1.
Test frequency : L : 100KHz /1.0V.
2.
All test data referenced to 25
℃
ambient.
3.
Heat Rated Current (Irms) will cause the coil temperature rise approximatelyΔt of 40
℃
(
keep 1min.).
4.
Saturation Current (Isat) will cause L0 to drop 30% typical.
(
keep quickly).
5.
Special inquiries besides the above common used types can be met on your requirement.
DC Bias Characteristics (Typical)
A
B
C
1
R0
E
D
1151
167
0
6.4
12.8
19.2
25.6
32
DCCURRENT(A)
0
7
14
21
28
35
TEMP. RISE(
o
C)
TMPC0624H-Series
R10
R33
R82
100
4
R7
0
14.4
28.8
43.2
57.6
72
DCCURRENT(A)
0
2.4
4.8
7.2
9.6
12
INDUCTANCE(uH)
TMPC0624H-Series
R10
R33
R82
4
R7
100
All the data list
e for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
For the latest specification, please visit our website:
Dimensions
Specifications
Chip Size
A
7.00
±
0.30
B
6.60
±
0.30
C
2.20
±
0.20
D
1.80
±
0.30
E
3.00
±
0.30
Units: mm
Part Number
I ductance L0
(
uH) @ 0 A
I rms
(
A)typ
I sat
(
A)typ
DCR (mΩ)
typ. @25
℃
.
DCR (mΩ)
max. @25
℃
.
TMPC0624H-R22MG-D
0.22
±20%
21.0
34.0
2.0
3.2
TMPC0624H-R47MG-D
0.47
±20%
15.0
26.0
4.8
5.1
TMPC0624H-R68MG-D
0.68
±20%
13.0
21.0
6.4
7.2
TMPC0624H-1R0MG-D
1.00
±20%
11.0
16.0
10.5
13.5
TMPC0624H-2R2MG-D
.20
±20%
7.0
14.0
23.0
28.0
TMPC0624H-3R3MG-D
3.30
±20%
6.0
10.0
34.0
39.0
TMPC0624H-4R7MG-D
4.70
±20%
5.5
9.0
41.0
50.0
TMPC0624H-5R6MG-D
5.60
±20%
5.0
8.0
56.0
62.0
TMPC0624H-6R8MG-D
6.80
±20%
4.0
7.0
65.0
72.0
TMPC0624H-100MG-D
10.0
±20%
3.2
5.0
92.0
101
Note:
1.
Test frequency : L : 100KHz /1.0V.
2.
All test data referenced to 25
℃
ambient.
3.
Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40
℃
(
keep 1min.).
4.
Saturation Current (Isat) will cause L0 to drop 30% typical.
(
keep quickly).
5.
Special inquiries besides the above common used types can be met on your requirement.
DC Bias Characteristics (Typical)
A
B
C
1
R0
E
D
1151
0
6.4
12.8
19.2
25.6
32
DC CURRENT(A)
0
7
14
21
28
35
TEMP. RISE(
o
C)
TMPC0624H-Series
R10
R33
R82
100
4
R7
0
14.4
28.8
43.2
57.6
72
DC CURRENT(A)
0
2.4
4.8
7.2
9.6
12
INDUCTANCE(uH)
TMPC0624H-Series
R10
R33
R82
4
R7
100
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or
notification.
For the latest specification, please visit our website:
Molding Type High Current Power Inductors
(2525
inch)
Dimensions
Specifications
Chip
A
B
C
D
E
Units: mm
Part Number
Inductance L0
(
uH) @ 0 A
I rms
(
A)typ
I sat
(
A)typ
DCR (mΩ)
typ. @25
℃
.
TMPC0624H-R22MG-D
0.22
±20%
21.0
34.0
2.0
TMPC0624H-R47MG-D
0.47
±20%
15.0
26.0
4.8
TMPC0624H-R68MG-D
0.68
±20%
13.0
21.0
6.4
TMPC0624H-1R0MG-D
1.00
±20%
11.0
16.0
10.5
TMPC0624H-2R2MG-D
2.20
±20%
7.0
14.0
23.0
TMPC0624H-3R3MG-D
3.30
±20%
6.0
10.0
34.0
TMPC0624H-4R7MG-D
4.70
±20%
5.5
9.0
41.0
TMPC0624H-5R6MG-D
5.60
±20%
5.0
8.0
56.0
TMPC0624H-6R8MG-D
6.80
±20%
4.0
7.0
65.0
TMPC0624H-100MG-D
10.0
±20%
3.2
5.0
92.0
Note:
1.
Test frequency : L : 100KHz /1.0V.
2.
All test data referenced to 25
℃
ambient.
3.
Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40
℃
(
keep 1min.).
4.
Saturation Current (Isat) will cause L0 to drop 30% typical.
(
keep quickly).
5.
Special inquiries besides the above common used types can be met on your requirement.
DC Bias Characteristics (Typical)
A
B
C
1
R0
E
D
1151
0
6.4
12.8
19.2
25.6
32
DC CURRENT(A)
0
7
14
21
28
35
TEMP. RISE(
o
C)
TMPC0624H-Series
R10
R33
R82
100
4
R7
0
14.4
28.8
43.2
5
DC CURRENT(A)
0
2.4
4.8
7.2
9.6
12
INDUCTANCE(uH)
TMPC0624H-Series
R33
R82
4
R7
100
167
