DC Bias Characteristics (Typical)
Dimensions
Specifications
Chip Size
Units: mm
A
5.70
±0.30
B
5.20
±0.20
C
1.60
±0.20
D
1.10
±0.30
E
2.50
±0.30
Part Number
Inductance L0 (uH)
±
20%
@ 0
A
I rms (A)
typ.
I sat (A)
typ.
DCR (m
Ω
)
typ. @25
℃
DCR (m
Ω
)
max. @25
℃
TMPC0518HP-R33MG-D
0.33
11.00
15.00
7.5
8.6
TMPC0518HP-R47MG-D
0.47
10.00
14.00
9.8
11.3
TMPC0518HP-R68MG-D
0.68
9.00
13.00
12.4
14.3
TMPC0518HP-1R0MG-D
1.0
6.80
10.00
18.2
21.0
TMPC0518HP-2R2MG-D
2.2
4.50
7.50
42.0
48.3
TMPC0518HP-3R3MG-D
3.3
3.50
5.00
60.0
69.0
TMPC0518HP-4R7MG-D
4.7
3.00
4.50
85.0
98.0
TMPC0518HP-5R6MG-D
5.6
2.50
4.00
110
127
TMPC0518HP-6R8MG-D
6.8
2.40
3.50
118
137
TMPC0518HP-100MG-D
10.0
2.30
2.80
165
190
TMPC0518HP-150MG-D
15.0
1.70
2.30
275
318
Note:
1.
Test frequency : L : 100KHz /1.0V.
2.
All test data referenced to 25
℃
ambient.
3.
Heat Rated Current (Irms) will cause the coil temperature rise approximately
Δ
t of 40
℃
(
keep 1min.).
4.
Saturation Current (Isat) will cause L0 to drop 30% typical. (keep quickly).
5.
Special inquiries besides the above common used types can be met on your requirement.
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogueare for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit our website:www.tai-tech.com.tw
Molding Type High Current Power Inductors
(2020
inch)
Dimensions
Specifications
Chip Size
A
5.70
±
0.30
B
5.20
±
0.20
C
1.60
±
0.20
D
1.10
±
0.30
E
2.50
±
0.30
Units: mm
Part Number
Inductance L0
(
uH)±20%
@ 0
A
I rms
(
A)typ
I sat
(
A)typ
DCR (mΩ)
Typ. @25
℃
.
DCR (mΩ)
max. @25
℃
.
TMPC0518HP-R33MG-D
0.33
11.00
15.00
7.5
8.6
TMPC0518HP-R47MG-D
0.47
