DC Bias Characteristics (Typical)
UHP 252012BF Series
1008
inch
Dimensions
Specifications
Chip Size
Units: mm
A 2.50 -0.10/+0.20
B
2.00 -0.10/
+0.20
C
1.20
max.
D
0.85
ref.
E
0.80
ref.
Part Number
Inductance
(
uH)
Test Frequency
(
Hz)
DCR (
Ω
)
±
20%
I sat (A) typ.
I sat (A) Max.
I rms (A) typ I rms (A) Max.
UHP252012BF-R47Y
0.47
±
30%
0.1
V/1M
0.028
4.00
3.60
3.70
3.35
UHP252012 BF-R68Y
0.68
±
30%
0.1
V/1M
0.036
3.00
2.70
3.30
3.00
UHP252012 BF-1R0Y
1.0
±
30%
0.1
V/1M
0.049
2.70
2.45
2.60
2.30
UHP252012 BF-1R5Y
1.5
±
30%
0.1
V/1M
0.063
2.30
2.05
2.20
1.95
UHP252012 BF-2R2M
2.2
±
20%
0.1
V/1M
0.080
2.15
1.95
1.85
1.65
UHP252012 BF-3R3M
3.3
±
20%
0.1
V/1M
0.120
1.70
1.50
1.45
1.30
UHP252012 BF-4R7M
4.7
±
20%
0.1
V/1M
0.176
1.50
1.35
1.20
1.05
UHP252012 BF-6R8M
6.8
±
20%
0.1
V/1M
0.250
1.15
1.00
1.00
0.90
UHP252012 BF-100M
10
±
20%
0.1
V/1M
0.410
0.85
0.75
0.75
0.65
UHP252012 BF-150M
15
±
20%
0.1
V/1M
0.540
0.63
0.56
0.60
0.54
UHP252012 BF-220M
22
±
20%
0.1
V/1M
0.850
0.56
0.50
0.50
0.45
Note:
Isat
：
Based on inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△
T
：
40
℃
.
）
Max
Sealed Type Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogueare for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit ourwebsite:www.tai-tech.com.tw
Sealed Type Power Inductors
(0806
inch)
Dimensions
Specifications
C
A
B
D
D
E
Chip Size
A
2.00
±
0.20
B
1.60
±
0.20
C
0.70
max.
D
0.60
ref.
E
0.80
ref.
Units: mm
DC Bias Characteristics (Typical)
0
100
200
300
400
DCcurrent(mA)
0
5
10
15
20
Inductance(uH)
HPC201607CF-100M
Part Number
Inductance
(
uH)
Tolerance
(%)
Test Frequency
(
Hz)
DCR
(
Ω
)
±
30%
Rated
Current(mA)
SRF
(
MHZ)min
HPC201607CF-100M
10
±
20%
0.1
V/1M
2.27
200
60.0
Note:
Isat
：
Basedon inductance change
（
△L/L0
：
≦
-30%
）
@
ambient temp.25
℃
Irms
：
Based on temperature rise
（
△T
：
40
℃.
）
Max
95
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specific
notification.
For the latest specification, please visit our website:
Sealed Type Power Inductors
(0806
inch)
Dimensions
Specifications
C
A
B
D
D
E
Chip Size
A
2.00
±
0.20
B
1.60
±
0.20
C
0.70
max.
D
0.60
ref.
E
0.80
ref.
Units: mm
DC Bias Characteristics (Typical)
0
100
200
300
400
DCcurrent(mA)
0
5
10
15
20
Inductance(uH)
HPC201607CF-100M
Part Number
Inductance
(
uH)
Tolerance
(%)
Test Frequency
(
Hz)
DCR
(
Ω
)
±
30%
Rated
Current(mA)
(
M
HPC201607CF-100M
10
±
20%
0.1
V/1M
2.27
200
Note:
Isat
：
Based on inductance change
（
△L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△T
：
40
℃.
）
Max
0
0.8
1.6
2.4
3.2
4
DCcurrent(A)
0
0.5
1
1.5
2
2.5
R47
R68
1
R0
2
R2
INDUCTANCE(uH)
UHP252012BF-SERIES
115
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the speci cations without prior noti cation.
For the latest speci cation, please visit our website:
Remark
