DC Bias Characteristics (Typical)
HPC 5012B Series
2020
inch
Dimensions
Specifications
Chip Size
Units: mm
A
4.90
±0.20
B
4.90
±0.20
C
1.20
max.
D
1.20
±0.20
E
3.30
±0.20
F
1.30
typ.
Part Number
Inductance (uH) Tolerance (%)
Test Frequency (Hz)
SRF (MHz)
min.
DCR (
Ω
)
±
20%
I sat (A)
I rms (A)
HPC5012B-1R0Y
1.0
±
30%
1
V100K
100
0.053
4.50
2.30
HPC5012B-1R5Y
1.5
±
30%
1
V100K
86
0.070
3.80
2.20
HPC5012B-2R2M
2.2
±
20%
1
V100K
70
0.085
3.10
2.00
HPC5012B-3R3M
3.3
±
20%
1
V100K
48
0.160
2.40
1.45
HPC5012B-4R7M
4.7
±
20%
1
V100K
40
0.180
2.20
1.40
HPC5012B-6R8M
6.8
±
20%
1
V100K
36
0.260
1.70
1.10
HPC5012B-100M
10
±
20%
1
V100K
26
0.420
1.40
0.85
HPC5012B-150M
15
±
20%
1
V100K
22
0.670
1.20
0.64
Note:
Isat
：
Based on inductance change
（
△
L/L0
：
≦
-30%
）
@
ambient temp. 25
℃
Irms
：
Based on temperature rise
（
△
T
：
40
℃
typ.
）
Sealed Type Power Inductors
Halogen
Halogen-free
Pb
Pb-free
All the data listed in this catalogueare for reference only,TAI-TECH reserves the right toalter or revise the specificationswithout prior
notification.
For the latest specification,please visit our website:www.tai-tech.com.tw
