Products Line Up
Hi-Current Power Inductors
Description Model P/N Package Size Inductance Range(uH) Irms (A) Isat (A) Page
Molding Type High
Current Power
Inductor
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
 Hi-Current Power Inductors
6
Description Model P/N Package Size Inductance
Range(uH)
Irms
(A)
Isat
(A) Page
Molding Type High Current
Power Inductor
MAHP
201610 0.24 – 4.70 1.00 – 3.00 1.00 – 4.20 151
252010 1.00 – 4.70 1.10 – 2.50 1.30 –2.70 152
252012 0.47 – 4.70 1.50 – 3.80 1.50 – 5.50 153
TMPC
0312H 0.47 – 10.00 1.00 – 5.00 1.40 – 7.20 154
0302H 0.10 – 10.00 1.40 – 10.5 1.60 – 14.0 155
0412HP 0.10 – 10.00 1.30 – 11.5 1.40 – 25.0 156
0402HP 0.33 – 22.00 1.20 – 10.0 1.40 – 18.0 157
0512HP 0.10 – 10.00 1.50 – 14.0 1.80 – 14.5 158
0515HP 0.20 – 22.00 1.20 – 15.0 1.70 – 22.5 159
0518HP 0.33 – 15.00 1.70 – 11.0 2.30 – 15.0 160
0502HP 0.22 – 15.00 1.90 – 15.0 2.80 – 25.0 161
0503HP 0.15 – 22.00 1.90 – 18.0 1.70 – 30.0 162
0612H 0.22 – 10.00 1.80 – 11.0 2.50 – 19.0 163
0615H 0.22 – 22.00 1.50 – 14.0 2.50 – 22.0 164
0618H 0.22 – 10.00 2.30 – 16.0 3.50 – 26.0 165
0602H 0.10 – 22.00 1.50 – 21.0 2.50 – 40.0 166
0624H 0.22 – 10.00 3.20 – 21.0 5.00 – 34.0 167
0603H 0.10 – 10.00 3.50 – 32.5 6.00 – 60.0 168
0604H 0.15 – 15.00 3.00 – 30.0 3.50 – 55.0 169
0605H 0.33 – 22.00 2.90 – 25.0 5.50 – 32.0 170
1004H 0.15 – 22.00 5.00 – 36.0 7.00 – 70.0 171
1005H 0.30 – 68.00 2.50 – 38.0 4.00 – 65.0 172
1235HP 0.10 – 10.00 7.00 – 43.0 14.0 – 84.0 173
1205HP 0.20 – 22.00 6.50 – 52.0 10.0 – 110.0 174
1206HP 1.00 – 47.00 5.50 – 29.0 7.00 – 45.0 175
1265HP 0.15 – 47.00 6.50 – 55.0 9.50 – 118 176
1707HP 1.00 – 100.00 5.30 – 52.0 6.50 – 60.0 177
MAHP
201610 0.24 – 4.70 1.00 – 3.00 1.00 – 4.20 151
252010 1.00 – 4.70 .10 – 2.50 1.30 –2.70 152
252012 0.47 – 4.70 1.50 – 3.80 1.50 – 5.50 153
All the data listed in this catalogue are for reference only, TAI-TECH reserves the right to alter or revise the specifications without prior
notification.
For the latest specification, please visit our website: www.tai-tech.com.tw
 Hi-Current Power Inductors
6
Description Model P/N Package Size Inductance
Range(uH)
Irms
(A)
Isat
(A) Page
Molding Type High Curr nt
Power Inductor
MAHP
201610 0.24 – 4.70 1.00 – 3.00 1.00 – 4.20 151
252010 1.00 – 4.70 1.10 – 2.50 1.30 –2.70 152
252012 0.47 – 4.70 1.50 – 3.80 1.50 – 5.50 153
TMPC
0312 H 0.47 – 10.00 1.00 – 5.00 1.40 – 7.20 154
0302 H 0.10 – 10.00 1.40 – 10.5 1.60 – 14.0 155
0412HP 0.10 – 10.00 1.30 – 11.5 1.40 – 25.0 156
0402HP 0.33 – 22.00 1.20 – 10.0 1.40 – 18.0 157
0512HP 0.10 – 10.00 1.50 – 14.0 1.80 – 14.5 158
0515HP 0.20 – 22.00 1.20 – 15.0 1.70 – 22.5 159
0518HP 0.33 – 15.00 1.70 – 11.0 2.30 – 15.0 160
0502HP 0.22 – 15.00 1.90 – 15.0 2.80 – 25.0 161
0503HP 0.15 – 22.00 1.90 – 18.0 1.70 – 30.0 162
0612 H 0.22 – 10.00 1.80 – 11.0 2.50 – 19.0 163
0615 H 0.22 – 22.00 1.50 – 14.0 2.50 – 22.0 164
0618 H 0.22 – 10.00 2.30 – 16.0 3.50 – 26.0 165
0602 H 0.10 – 22.00 1.50 – 21.0 2.50 – 40.0 166
0624 H 0.22 – 10.00 3.20 – 21.0 5.00 – 34.0 167
0603 H 0.10 – 10.00 3.50 – 32.5 6.00 – 60.0 168
0604 H 0.15 – 15.00 3.00 – 30.0 3.50 – 55.0 169
0605 H 0.33 – 22.00 2.90 – 25.0 5.50 – 32.0 170
1004 H 0.15 – 22.00 5.00 – 36.0 7.00 – 70.0 171
1005 H 0.30 – 68.00 2.50 – 38.0 4.00 – 65.0 172
1235HP 0.10 – 10.00 7.00 – 43.0 14.0 – 84.0 173
1205HP 0.20 – 22.00 6.50 – 52.0 10.0 – 110.0 174
1206HP 1.00 – 47.00 5.50 – 29.0 7.00 – 45.0 175
1265HP 0.15 – 47.00 6.50 – 55.0 9.50 – 118 176
1707HP 1.00 – 100.00 5.30 – 52.0 6.50 – 60.0 177
TMPC
0312H 0.47 – 10.00 1.00 – 5.00 1.40 – 7.20 154
0302H 0.10 – 10.00 1.40 – 10.5 1.60 – 14.0 155
0412HP 0.10 – 10.00 1.30 – 11.5 1.40 – 25.0 156
0402HP 0.33 – 22.00 1.20 – 10.0 1.40 – 18.0 157
0512HP 0.10 – 10.00 1.50 – 14.0 1.80 – 14.5 158
0515HP 0.2 – 22.0 1.20 – 15.0 1.70 – 22.5 159
0518HP 0.33 – 15.00 1.70 – 11.0 2.30 – 15.0 160
0502HP 0.22 – 15.00 1.90 – 15.0 2.80 – 25.0 161
0503HP 0.15 – 22.00 1.90 – 18.0 1.70 – 30.0 162
0612H 0.22 – 10.00 1.80 – 11.0 2.50 – 19.0 163
0615H 0.22 – 22.00 1.50 – 14.0 2.50 – 22.0 164
0618H 0.22 – 10.0 2.30 – 16.0 3.50 – 26.0 165
0602H 0.10 – 22.00 1.50 – 21.0 2.50 – 40.0 166
0624H 0.22 – 10.0 3.20 – 21.0 5.00 – 34.0 167
0603H 0.10 – 10.00 3.50 – 32.5 6.00 – 60.0 168
0604H 0.15 – 15.00 3.00 – 30.0 3.50 – 55.0 169
0605H 0.33 – 22.00 2.90 – 25.0 5.50 – 32.0 170
1004H 0.15 – 22.00 5.00 – 36.0 7.00 – 70.0 171
1005H 0.30 – 68.00 2.50 – 38.0 4.00 – 65.0 172
1235HP 0.10 – 10.00 7.00 – 43.0 14.0 – 84.0 173
1205HP 0.2 – 22.00 6.50 – 52.0 10.0 – 110.0 174
1206HP 1.00 – 47.00 5.50 – 29.0 7.00 – 45.0 175
1265HP 0.15 – 47.00 6.50 – 55.0 9.50 – 118 176
1707HP 1.00 – 100.00 5.30 – 52.0 6.50 – 60.0 177
6
